Technical Data  S 2700 (   )

1.

Displacement

2660 cm3

2.

Compression Ratio

10 : 1

3.

Bore

97  mm

4.

Stroke

90  mm

5.

min Power Output

105 hp / 77 kW  bei 3000 rpm

6.

Oil Content

3.5  Liters

7.

Oil temperature range

40    120C / 104 - 250 F

8.

Oil pressure range

2.5   4.5 bar

9.

Ignition System

Slick 4330 single- or magneto Dual

electronic dual ignition optionally for

automotive sparks plugs

10.

Fuel type

Avgas 100 LL or unleaded 98 octane

11.

Cylinder head temperature

max. 230C / 450F

12.

Generator

14 / 18 / 45 Amp. 12 V

13.

Starter

1 : 3.7 / 12 V

14.

Carburettor

1 x Bing 94/40 or 2 x Bing 64/32

15.

Cooling vanes

4 x System Sauer

16.

Hydraulic Valve Tappets

8 x H 190

18.

Dry Mass

75 kg / 188 lb
